― 25 ―
7.2.3Testing
(1)PresstheTESTBUTTON.
(2)MeasuredresultisdisplayedonLCD.
Ifthemeasured resultis100Vormore,"UcHV"isdisplayedon
LCD.
Note：WhenTestLeadremovedduringameasurement,"no"is
displayedon LCD and a measurement will be stopped. Please
checkTestLeadisrightlyconnected.
If"I⊿n"settingisgraterthantheratedresidualcurrentofRCD,
RCDwilltripand"no"maybedisplayedonLCD.
8.AUTO-TEST
Whenapplyingvoltagetotheinstrument,withTestbuttonisturnedand
beinglocked,voltagevalue is displayedonLCD.And3sec.later,a
measurementonselectedfunctionisperformedautomatically.Besure
toreleasethelockedTestbuttonafterameasurement.
9.STORE/RECALLAMEASUREDRESULT
Measured result at each function can be stored in the memory of the
instrument.(MAX:300)
9.1Howtostoredata
Storetheresultaccordingtofollowingsequence.
(1)Afterameasurement,pressMEMORYMODESWITCH("MEM
MODE"SWITCH) while measuredresult is beingdisplayed. Then
instrumentbecomesMEMORYMODE,and" MEM"markappears
ontheLCD.Theactionofeachswitchchangesasshownunder
eachswitch.
(2)SelecttheDataNoyouwanttostorewithMEMORYSELECT
SWITCH("MEM▼▲"SWITCH).
(3)DecideitwithENTERSWITCH("ENT"SWITCH).
(4)SelectthePlaceNoyouwanttostorewithMEMORYSELECT
SWITCH("MEM▼▲"SWITCH).
