3.FEATURES
3.1InstrumentLayout
1......LCD
2......RCDFUNCTIONSELECTSWITCH
(MEMORYRECALLSWITCH)
3......0°/180°SELECTSWITCH
(ENTERSWITCH)
4......ULVALUESELECTSWITCH
(MEMORYCLEARSWITCH)
5......TESTBUTTON
6......WIRINGCHECKLED
LEDindicationofcorrectpolarityisthattheP-EandP-NLEDsare
lit.PandNarereversedwhenthe reverseLEDislit.
7......"I⊿n/LOOP/PSC"SELECTSWITCH
(MEMORYSELECTSWITCH)
8......MEMORYMODESWITCH
(MEMORYMODEEXITSWITCH)
9......FUNCTIONSWITCH
OperationatMemorymodeisshownin().
1
6
7
8
9
2
3
4
5
Fig.3
