6-4 ACVoltageMeasurement
# DANGER
󱾀 Toavoidelectricshock,nevermakemeasurementonacircuitin
thefollowingcategories;
Measurementcategory Ⅳ (CAT. Ⅳ ):overAC600V
Measurementcategory Ⅲ (CAT. Ⅲ )orlower:overAC750V
󱾀 Do not make measurement with the battery compartment cover
removed
󱾀 Keep your fingers and hands behind the barrier during
measurement.
a.SettheFunction Selectorswitchtothe"400V"or"750V"position.
IftheinstrumentisintheDCmode,presstheAC/DCbuttononce
to select the AC mode. (The instrument is set to the AC mode
whenit is powered on.) The"AC" shouldbe shownon theupper
leftcornerofthedisplay.
b.Slidetheterminalcovertotheleft.Plugtheredtestleadintothe
V/
Ω terminalandtheblacktestleadintotheCOMterminal.
c.Connectthetipofthetestleadstothecircuitundertest.Takethe
readingonthedisplay.
