KYORITSU KEW 2003A - Instrument Layout

 9 
4. Instrument Layout
① TransformerJaws:Includecurrentsensors
② JawTrigger:Usedtoopenandclosethetransformerjaws
③ FunctionSelectorSwitch
Selects function to use. Also switches off the instrument when
settothe"OFF"position.
④ DataHoldButton
Freezes the display reading with   symbol shown on the
displaywhenpushedin.
①
⑯
⑮
②
③
④
⑧
⑦
⑨
⑤
⑥
⑬
⑩ ⑪ ⑫
⑭
