 10 
⑤ AC/DCButton
UsedtoswitchtheinstrumentbetweentheACandDCmodes.
The instrument is set to the AC mode when it is powered on.
PressthisbuttontoselecttheDCmode.
⑥ ModeButton
A press of this button on a current or voltage range turns the
instrumenttotheMAXmeasurementmodewith
  shownon
thedisplay.PressthebuttonagaintoexittheMAXmode.
 Apressofthebuttonontheresistancerangeturnstheinstrument
to thecontinuity checkmode with
 symbol shownon the
display.Inthismode,thebuzzerbeepswhenthereadingisabout
50
Ω orless. Press the button again to exit the continuitycheck
mode.
⑦ ZeroADJ./RESETButton
Used forzero adjustment on 400A DC range or for resetting
the reading in theMAX mode.
  symbol is shown onthe
display when zero adjustment is enabled on 400A DC range.
(Zeroadjustmentisavailableonlyon400ADCrange.)
⑧ LCDDisplay
Fieldeffect typeofliquid crystaldisplaywith maximumcounts
of 3999 and microprocessor-controlled annunciators and the
decimalpoint.
