Kzyee KM50 - KM50 Technical Specifications; Tool Specifications; Electrical Specifications

Vehicle Super Probe
- 4 -
3. Product Specifications
(1) Tool Specifications
Display TFT color display (160x128 dpi )
Operating Temperature 0 to 60℃ ( 32 to 140℉)
Storage Temperature -5 to 70℃ (-40 to 185℉ )
Dimensions (L*W*H) 200mm*52mm*39mm
Net Weight 0.48Kg
(2) Electrical Specifications
Supply Voltage 8V DC ~ 30V DC
DC/ AC Voltage Test -110V ~ 110V
Frequency 0Hz ~ 1Mhz
Duty Cycle 0.0~100.0%
Fuel Injection Voltage: 0~180V, Time: 0~25ms
Resistance 0~1MΩ
Diode Germanium diode, silicon diode
Rating Current 1A~8 A
 Instrument Trip Time:
8 Amps: Hold > 1 hour.
12 Amps: current: trip in one hour.
16 Amps: current: trip in 3-30 seconds.
24 Amps: current: trip in 0.5-4.0 seconds.
