4.5 SAFETY RULES
L-ACOUSTICS loudspeakers can be ceiling-suspended or attached to a wall (vertical orientation only)
using accessories that are either supplied or recommended by L-ACOUSTICS only. Installation must
be done according to the following instructions :
Instructions
Loudspeaker
Model
Accessory
model
Wood support Incompressible plain support
(concrete or equivalent)
108P ETR8-2 Use 3 x self tapping screws with
minimum 8 mm diameter and 60
mm length (hexagonal head screw
DIN571 or equivalent)
Use 3 x anchors for heavy load 8
mm diameter and 50 mm length
minimum
112P ETR112XT Use 3 x self tapping screws with
minimum 8 mm diameter and 80
mm length (hexagonal head screw
DIN571 or equivalent)
Use 3 x anchors for heavy load
(10 mm diameter and 50 mm
length minimum)
112P XTLIFTBAR
Do not suspend the loudspeaker
from this type of support
Use a tested rigging point (130 kg)
and in conformity with national
safety regulations of the country
of installation
SB15P ETR15P Use 3 x self tapping screws with
minimum 8 mm diameter and 80
mm length (hexagonal head screw
DIN571 or equivalent)
Attach M8 (8 mm diameter) I-bolt
to rear threaded insert for
attachment of safety steel
Use 3 x anchors for heavy load
(10 mm diameter and 50 mm
length minimum)
Attach M8 (8 mm diameter) I-bolt
to rear threaded insert for
attachment of safety steel
The 108P or 112P can be used with a loudspeaker stand (L-ACOUSTICS recommends the K&M
21435 or equivalent). The footprint (base diameter) must be at least 1300 mm and withstand a
maximum centric load of 350 N (35 kg) or higher. Tripod stand legs must be completely opened and
the height must not exceed 2020 mm when used with the 108P and 1420 mm when used with the
112P.
Always ensure that the ETR112XT or ETR15P rotating arm is securely fastened by verifying that the
spring-loaded locking pin at the pivot point is correctly seated before adjusting the tilt angle of the
112P or SB15P.
When using ETR8-2, ETR112XT or ETR15P in the vertical orientation, always install the U-bracket
with the fixed arm on the bottom and the pivoting arm on top.
Maximum one 112P can be rigged per XTLIFTBAR.
L-ACOUSTICS recommends the use of safety steels at all times.
Attachment to concrete has not been investigated during the CSA approval.
