6.5 Rigging the 8XT or 12XT enclosure with the OMNIMOUNT
®
accessories
Four predrilled inserts located on the rear face of the 8XT and 12XT enclosures allow for mounting the
OMNIMOUNT
®
rigging accessories.
Figure 19: Inserts on the 12XT enclosure
Remove the four screws (they will be employed for fixing the rigging accessory) from the four predrilled inserts and
follow the mounting instructions (provided by the OMNIMOUNT
®
manufacturer) regarding the:
• OMNIMOUNT
®
30.0 SERIES mounting accessories for the 8XT enclosure,
• OMNIMOUNT
®
120.0 SERIES mounting accessories for the 12XT enclosure.
L-ACOUSTICS recommends using an additional safety point when rigging enclosures.
A safety eye-bolt accessory can be added using the M8* insert located on the rear face of the
enclosure (see Figure 19).
* The “M8” notation refers to the European standard (see applicable external documentation).
Four predrilled inserts
for OMNIMOUNT
®
mounting accessory
Safety insert for safety
eye-bolt accessory
!
WARNING
