12XT COAXIAL ENCLOSURE
user manual
VERSION 1.2
12XT_UM_ML_1.2
www.l-acoustics.com
6 en
4 XT COAXIAL RANGE
The L-ACOUSTICS
®
12XT active/passive enclosure is the mid sized model within the L-ACOUSTICS
®
XT
Coaxial Range and operates over the 55 Hz to 22 kHz frequency bandwidth. The system response can be extended
down to 32 Hz with the addition of the L-ACOUSTICS
®
SB118 subwoofer.
The system approach developed by L-ACOUSTICS
®
for the XT range consists of the elements needed to fully take
advantage of the possible configurations and optimize the system. The main components of the system are:
8XT

Passive compact coaxial enclosure
12XT

Active/passive multipurpose coaxial enclosure
115XT HiQ

Active coaxial stage monitor
ETR8-2

Mounting accessory for the 8XT enclosure
ETR12

Mounting accessory for the 12XT enclosure
ETR15

Mounting accessory for the 115XT HiQ enclosure
XTLIFTBAR

Rigging accessory for the 12XT and 115XT HiQ enclosures
SB118

Subwoofer enclosure
LA4

Medium power amplified controller
LA RAK

Amp rack containing three LA8 high power amplified controllers
LA NETWORK MANAGER

Software for remote controlling the amplified controllers
SOUNDVISION

Acoustical and mechanical modeling software
Figure 1: XT range components (part 1)
ETR8-2
ETR12
ETR15
12XT
115XT HIQ
8XT
XTLIFTBA
R
SB118
