L-Acoustics K3 - Loudspeaker ConGurations; Line Source

Loudspeaker congurations
Loudspeaker congurations
Line source
Deployed as a line source, the system operates over the nominal bandwidth of the K3 enclosure, with an adjustable
horizontal directivity.
The [K3 70], [K3 90], and [K3 110] presets allow for a reference frequency response in long throw applications. Each
preset is dedicated to a horizontal directivity setting.
K3 is driven by the LA4X / LA8 / LA12X amplied controllers.
Enclosure K3
Preset [K3 70] [K3 90] [K3 110]
Frequency range (-10 dB) 42 Hz - 20 kHz
K3 owner's manual (EN) version 1.0 37
