Loudspeaker congurations
Additional downll element
All K3 system congurations can be combined with an additional Kara / Kara II line source downll system. This allows
an extension of the vertical coverage to the closer audiences.
Kara / Kara II
The Kara / Kara II enclosures are driven by the LA4X / LA8 / LA12X amplied controllers.
Enclosure K3 Kara II or Kara
Preset [K3 70] [K3 90] [K3 110] [KARAIIDOWNK3] [KARADOWNK3]
Frequency range (-10 dB) 42 Hz - 20 kHz
Do not add any delay between the K3 and Kara / Kara II elements of a mixed line source.
Using the Kara / Kara II system
Refer to the Kara II owner's manual for the operating modes of Kara / Kara II as a main system.
40 K3 owner's manual (EN) version 1.0

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the L-Acoustics K3 and is the answer not in the manual?

L-Acoustics K3 Specifications

General IconGeneral
Maximum SPL143 dB
Nominal ImpedanceLF: 8 Ω, MF: 8 Ω, HF: 8 Ω
Amplified ControllerLA12X
Weight43 kg / 95 lb
LF Transducers2 x 12''
HF Transducers1 x 3" diaphragm compression driver
Components2 × 12'' LF
Enclosure MaterialBaltic birch plywood
Connectors2 x NL4
Recommended AmplifierLA12X
Coverage Angle70° horizontal
