Inspection and preventive maintenance
K3 array with K3-CHARIOT and K2-JACK
Refer to Rigging part inspection (p.42).
the screw of the grill locking
system is present
Ball-locking pins (p.50)
Rigging check (p.53)
rear rigging arms rotate correctly
the locking handles can be tightened
and loosened by hand
turn the hand wheels:
the central part is raised
(clockwise) or lowered
(counter-clockwise)
check the integrity of the
quarter-turn locking system
K3 owner's manual (EN) version 1.0 47
