L-Acoustics K3 User Manual

Rigging procedures
Attaching K2-JACK stabilizers to K3-CHARIOT
Type of deployment stacked array
Rigging accessory K2-JACK
K3-CHARIOT
Min number of operators 2
Procedure
1. Attach the K2-JACK to the K3-CHARIOT:
a) Insert the K2-JACK studs through the K3-CHARIOT.
b) Raise and turn the K2-JACK handles to secure the locking system.
K3 owner's manual (EN) version 1.0 89

L-Acoustics K3 Specifications

General

Maximum SPL	143 dB
Nominal Impedance	LF: 8 Ω, MF: 8 Ω, HF: 8 Ω
Amplified Controller	LA12X
Weight	43 kg / 95 lb
LF Transducers	2 x 12''
HF Transducers	1 x 3" diaphragm compression driver
Components	2 × 12'' LF
Enclosure Material	Baltic birch plywood
Connectors	2 x NL4
Recommended Amplifier	LA12X
Coverage Angle	70° horizontal
