L-Acoustics K3 User Manual

Rigging procedures
Rigging procedures
Preparing a block of four K3
Type of deployment stacked array
Rigging accessory K3-CHARIOT
Min number of operators 2
Procedure
1. Prepare K3-CHARIOT.
Fully rotate the rear rigging arms of K3-CHARIOT to attach a rst K3.
2. Position a rst K3 on K3-CHARIOT.
K3 owner's manual (EN) version 1.0 61

L-Acoustics K3 Specifications

General

Maximum SPL	143 dB
Nominal Impedance	LF: 8 Ω, MF: 8 Ω, HF: 8 Ω
Amplified Controller	LA12X
Weight	43 kg / 95 lb
LF Transducers	2 x 12''
HF Transducers	1 x 3" diaphragm compression driver
Components	2 × 12'' LF
Enclosure Material	Baltic birch plywood
Connectors	2 x NL4
Recommended Amplifier	LA12X
Coverage Angle	70° horizontal
