L-Acoustics K3 - Transporting; Stacking Multiple K3-CHARIOTLID on K3-CHARIOT

Rigging procedures
Transporting
Stacking multiple K3-CHARIOTLID on K3-CHARIOT
Type of deployment stacked array
Rigging accessory K3-CHARIOTLID
K3-CHARIOT
Min number of operators 1
Prerequisite
The rear rigging arms of K3-CHARIOT are on storage position.
Procedure
1. Position one K3-CHARIOTLID on K3-CHARIOT.
The longer side must be on the rear rigging arms of K3-CHARIOT.
2. Secure K3-CHARIOTLID to the front rigging arms of K3-CHARIOT using the locking pin.
3. Position another K3-CHARIOTLID (reverted) on the rst one.
The longer side must be on the front side of K3-CHARIOT.
94 K3 owner's manual (EN) version 1.0
