L-Acoustics K3 - Flying; Flying an Array with K3-BUMP and K3-BAR

Rigging procedures
Flying
Flying an array with K3-BUMP and K3-BAR
Type of deployment own array
Rigging accessory K3-BUMP
2 × Ø19 mm shackles WLL 3.25 t (provided)
K3-BAR
Min number of operators 2
Prerequisite
Preset inter-enclosure angles
Preset the inter-enclosure angles before performing this procedure. Refer to Pre-setting the inter-enclosure angles
(p.65).
Procedure
1. Prepare a block of K3 enclosures. Refer to Preparing a block of four K3 (p.61).
2. Connect K3-BAR to K3-BUMP.
a) Remove the pins from K3-BAR and position K3-BAR on K3-BUMP.
Refer to Soundvision to identify the extension and position of the bar.
K3 owner's manual (EN) version 1.0 67
