10.3) MANUAL RELEASE
The models Fail Secure ET-FSE and Bistable ET-BIS are
equipped with the ET-SMA manual release system that is used to
release the electric lock in the case of a power failure, and
therefore move the leaves freely.
C
Secure the bottom of the release handle to the side panel, using
the self-tapping screws provided.
Respect the positions indicated in the opposite figure.
RELEASE HANDLE FASTENING
A
B
For fastening on both the right and left side of the automation, you
need to fasten the adjustment register on the bottom of the
release handle.
Insert the steel cable inside the flexible sheath as shown in the
figure.
