Apply the adhesive label as shown in the figure, taking the four
black bands on the label as a reference, which must be
positioned in correspondence of the 4 cardinal points.
Insert the steel cable end into the release handle as shown in the
figure and fasten the handle to the bottom with the special screw.
SCREW COVER
LABEL
Apply the screw cover label on the fastening screw.
By moving the release handle to the UNRELEASED position,
only the orange part of the label with the drawn arrows must be
visible.
D
E
F
Insert the flexible sheath inside the side panel.
LEFT SIDE PANEL
RIGHT SIDE PANEL
