Label ETERNA 90 EASY User Manual

OA-FLEX T
INTERNAL RADAR
ACTIVATION AND CLOSING SAFETY SENSOR
UR24
+
-
+
-
10
E.C.1
pink
19
24V(+)
white
20
0(-)
brown
17
TEST(+)
red
18
0(-)
black
ACTIVATION
8
COMMON
yellow
6
RADAR IN.
green
+
-
+
-
19
24V(+)
white
20
0(-)
brown
17
TEST(+)
red
18
0(-)
black
13
COMMON
blue
8
COMMON
yellow
7
RADAR EXT.
green
T-EASY
230Vac
SAFETY
OUTPUT
POWER
SAFETY
INPUT
OA-FLEX T
EXTERNAL RADAR
ACTIVATION AND CLOSING SAFETY SENSOR
ACTIVATION
SAFETY
OUTPUT
POWER
SAFETY
INPUT
ELECTRICAL CONNECTIONS ETERNA EASY 90
Application with two OA-FLEX - activation and safety sensor in closing
To activate the operating of the safety sensor in closing EC1 set dip-switch 1 of S3 = OFF
To activate the operating of the safety sensor in closing EC2 set dip-switch 1 of S2 = ON
To activate the closing safety sensor test set dip-switch 3 of S2 = ON (as request by EN16005 European standard)
Set safety input "LOW" (dip 12 = ON) on OA-FLEX T sensor
2
ELECTRIC LOCK
FAIL SAFE
FAIL SECURE
MOTOR
WITH ENCODER
BATTERY 18V
EARTH NEUTRAL
PHASE
POWER SUPPLY
SWITCH
17 18
TEST
+
A B
-
FUNCTION
PS3PS1
11
COMMON
blue
14
E.C.2
AUX1
pink
E.C.2
