Label ETERNA 90 EASY User Manual

UR24
T-EASY
230Vac
ELECTRICAL CONNECTIONS ETERNA EASY 90
Application with two OA-PRESENCE T safety sensor in opening
To activate the operating of the safety sensor in opening EO1 set dip-switch 2 of S3 = OFF.
To activate the operating of the safety sensor in opening EO2 set dip-switch 2 of S2 = ON.
To activate the opening safety sensor test set dip-switch 4 of S2 = ON (as request by EN16005 European standard)
Set safety input "LOW" (dip 10 = ON) on OA-PRESENCE T safety sensor.
SAFETY SENSORS FOR OPENING
+
-
+
-
12
E.0.1
blue
19
24V(+)
red
20
0(-)
green
17
TEST(+)
brown
18
0(-)
orange
+
-
+
-
19
24V(+)
red
20
0(-)
green
17
TEST(+)
brown
18
0(-)
orange
13
COMUNE
white
SAFETY
OUTPUT
POWER
SAFETY
INPUT
SAFETY
OUTPUT
POWER
SAFETY
INPUT
3
ELECTRIC LOCK
FAIL SAFE
FAIL SECURE
MOTOR
WITH ENCODER
BATTERY 18V
EARTH NEUTRAL
PHASE
POWER SUPPLY
SWITCH
FUNCTION
PS3PS1
+
A B
-
17 18
TEST
11
COMUNE
white
15
E.0.2
AUX2
blue
E.O.2
OA-PRESENCE T
