FUNCTION TABLE DIP-SWITCH S1
FUNCTION STATUS EXPLANATION
DIP 1
OFF
Automation type selection: ETERNA EASY 150
(doors up to a maximum weight of 150 kg per leaf).
ON
Automation type selection: ETERNA EASY 90
(doors up to a maximum weight of 90 kg per leaf).
DIP 2
OFF
Electric lock type selection: ET-FSE - FAIL SECURE
ON
Electric lock type selection: ET-FSA - FAIL SAFE
DIP 3
OFF
Standard function: the electric lock activates when the door is closed only in the
Night Lock work program.
ON
Bank function: the electric lock activates when the door is closed in all work programs
DIP 4
OFF
Operation when powered by battery: if the mains power supply is off the door keeps
working normally.
ON
Operation when powered by battery: if the mains power supply is off the door opens
and stays open in the automatic work programs.
DIP 5
OFF
Battery monitoring: if the battery is low or damaged the control unit buzzer beeps
before the door opens for ten cycles.
ON
Battery monitoring: if the battery is low or damaged, the door opens and stays open
in automatic programs.
DIP 6
OFF
Night lock program: OPEN and START inputs are enable to open the door.
ON
Internal Radar enabling time when the Night Lock work program is selected.
The Internal Radar input remains enabled for 25 seconds to open the door after the
Night Lock work program has been set.
DIP 7
OFF
Stop input (terminal 16): it works as a stop command.
Set N.O. / N.C. status by dip-switch 6 of S2.
ON
Stop input (terminal 16): it works as switch for day / night function selection.
If the input has the contact open, the door works in day mode (active radars).
If the input has the contact close the door works in night mode (disactive radars).
DIP 8
Not used
27
