Label ETERNA 90 EASY User Manual

FUNCTION TABLE DIP-SWITCH S2
FUNCTION
STATUS
EXPLANATION
DIP 1
OFF
E.E.C.2 closing safety sensor input inactive
When the safety sensor is not installed on the E.C.2 - AUX1 input (terminal 13-14).
ON
E.E.C.2 closing safety sensor input active
Closing safety sensor installed on E.C.2 - AUX1 input (terminal 13-14).
See electrical connections “drawing 2”.
DIP 2
OFF
E.O.2 opening safety sensor input inactive.
When the safety sensor is not installed on the E.O.2 - AUX2 input (terminal 13-15).
ON
E.O.2 opening safety sensor input active.
Opening safety sensor installed on E.O.2 - AUX2 input (terminal 13-15).
See electrical connections “drawing 3”.
DIP 3
Function active if
dip 1 / S2 = ON or
dip 1 / S3 = OFF
OFF
Test on closing safety sensors E.C.1 and E.C.2 inactive; for sensors which are not
pre-arranged for the monitoring.
ON
Test on closing safety sensors E.C.1 and E.C.2 active; for sensors pre-arranged for
automatic door monitoring by the automation (cat.2/pl.c comply EN16005 standard).
DIP 4
Function active if
dip 2 / S2 = ON or
dip 2 / S3 = OFF
OFF
Tests on opening safety sensors E.O.1 and E.O.2 inactive; for sensors which are not
pre-arranged for the monitoring.
ON
Test on opening safety sensors E.O.1 and E.O.2 active; for sensors pre-arranged for
automatic door monitoring by the automation (cat.2/pl.c comply EN16005 standard).
DIP 5
OFF
OPEN input conguration: normally open contact.
If not used or if a device with N.O. contact is installed.
ON
OPEN input conguration: normally closed contact.
If a device with N.C. contact is installed.
DIP 6
OFF
STOP input conguration: normally open contact N.O.
ON
STOP input conguration: normally closed contact N.C.
DIP 7
OFF
PRJ38 FT1/FR1 photocell: not installed.
ON
PRJ38 FT1/FR1 photocell: installed. It works as set by dip 8 of S2.
DIP 8
Function active if
dip 7 / S2 = ON
OFF
PRJ38 FT1/FR1 photocell: it works as stop command.
ON
PRJ38 FT1/FR1 photocell: it works as safety in closing.
See electrical connections “drawing 1”.
FUNCTION TABLE DIP-SWITCH S3
FUNCTION
STATUS
EXPLANATION
DIP 1
OFF
E.E.C.1 closing safety sensor input active
Closing safety sensor installed on E.C.1 input (terminal 10-11).
See electrical connections “drawing 2”.
ON
E.E.C.1 closing safety sensor input inactive
When the safety sensor is not installed on the E.C.1 input (terminal 10-11).
DIP 2
OFF
E.O.1 opening safety sensor input active.
Opening safety sensor installed on E.O.1 input (terminal 11-12).
See electrical connections “drawing 3”.
ON
E.O.1 opening safety sensor input inactive.
When the safety sensor is not installed on the E.O.1 input (terminal 11-12).
28
