POTENTIOMETERS TABLE
POTENTIOMETER EXPLANATION
TM1
Opening speed. Max. 0,8 m/s per leaf.
Increasing the value will increase speed during the opening process.
TM2
Closing speed. Max. 0,6 m/s per leaf.
Increasing the value will increase speed during the closing process.
TM3
Reduced opening distance during winter. Min. 20 cm per leaf.
Adjustment of the reduced opening space in percentage of the free passage.
TM4
Motor thrust power.
Adjustment of motor power during door movement.
At maximum value, the maximum motor thrust is obtained.
The automation has a safety system that stops and reverses movement of the door if the
power limit is exceeded.
TM5
Open door pausing time.
Adjustable range from 0 (closing immediately after opening) to 30 seconds.
TM6
Sensitivity to the obstacle.
Adjustment of the pushing time against the obstacle before the reversal of the movement.
Increasing the value increases the pushing time and decreases the sensitivity.
29
