SPARE PARTS AND ACCESSORIES
Lungs
Problem
– Lungs not functioning properly.
Possible Solution
– Check that the airway resistance is not set to maximum in the
Instructor Application.
– Open the torso and chest plate. Check that the lungs are free to
expand and are not restricted by any cables.
– Check that the lung bladders are properly connected, and that
the tubes are not twisted.
– Check that the lung bladders are in a horizontal position and
inserted correctly. Ensure that the lung compliance O-rings lie
between the folds of the lung bladders.
– Check for flaws or ruptures in the lung bladders.
– Check that the two lung compliance O-rings are fitted correctly.
Replace O-rings if they appear to be damaged.
– Check that there are no obstructions inside the simulator
airways which may block air flow.
– If there is no change when adjusting lung compliance, contact
Laerdal Technical Service.
– If there is no change in lung resistance, contact Laerdal Technical
Service.
Mechanical Noise during Auscultation
In the Instructor Application, click <auscultation focus>.
Batteries
Problem
– Battery life is less than 150 minutes with healthy patient and fully
charged batteries.
Possible Solutions
– Batteries may be old, (recommended lifetime is 200 discharge
cycles). Insert new batteries.
– Compressor may not function properly; consult your local
Laerdal Technical Services Centre.
Pulses
Problem
– Cannot feel pedal pulses
Possible Solutions
– Skin may be too tight over pulse units – readjust skin and reboot.
Clinical Features - Pneumothorax Bladders
Problem
– Experience problems with pneumothorax bladders.
Solution
– Check tubing connection at base of the bladder, to ensure that
tubing has not been disconnected.
Simulator Shutdown
Problem
– The Patient Simulator is unresponsive.
Solution
Press and hold the <ON/OFF> button for 10 seconds to force the
Patient Simulator to shutdown.
Spare Parts and Accessories
For latest version of Spare Parts and Accessories, visit
www.laerdal.com
Catalogue Numbers
Transport and Storage Cases
212-17950 Case soft, torso
212-18050 Case soft, legs
212-07150 Carry Case, Rugged
Patient Simulator Parts
212-00050 SimMan 3G Patient Simulator - Standard Version
212-11350 Arm bushing (left and right)
212-13050 Arm right, IV arm complete
212-14050 Arm left, BP Arm complete
212-16060 Leg right, complete
212-16050 Leg left, complete
380460 Neutral Genitalia (default)
212-12950 Female Genetalia
212-12850 Male Genetalia
212-12250 Battery Patient Simulator, internal (pkg. 2)
212-12350 Thigh-joint connector
212-12450 Battery clip, Patient Simulator internal
212-12550 Panel cover (left and right)
381107 Soft Teeth
212-14250 Arm Adaptor SimMan/SimMan 3G
212-29650 Headset + Mic USB Connector
Power cords
260305 US cord
260306 EUR cord
212-18650 PC Power Pack (110-240V)
260307 UK cord
200-30515 AUS power cord
212-07050 External Battery Charger
PCs and Equipment
Visit www.laerdal.com for the latest versions and catalogue
numbers
SimMan 3G Clothing
212-17450 Shirt
212-17650 Boxer Shorts
212-17750 Belt
212-17550 Trousers
Fluid and Blood System Equipment
212-17150 Blood Fill Unit
212-18950 Fluid Fill Unit
300-00750 Blood Concentrate
212-20050 Wound Tape Kit
212-18550 Wounds Kit
Drugs and RFID Tags
210-70050 Drug / Airway Tag Kit
212-17850 Sleeve Medication / Airway Tags
212-23150 IV Filter (pkg. 6)
212-23250 Fastening hooks for RFID base
212-23350 Vial Kit (5 x 10ml & 5 x 20ml)
212-13450 Lock Kit for catheter, International (2 sets of 4)
212-13550 Lock kit for catheter, US (2 sets of 4)
212-13650 IV Catheter, luer lock, male (pkg. 40)
212-13250 IV Catheter with lock, US version (one port)
212-13350 IV Catheter with lock, International version
(two ports)
Consumables
212-21050 Neck Skin Kit (6)
212-24050 Torso Skin
212-24450 Torso Skin Sternal IO
212-13150 Skin right, arm
212-14150 Skin left, arm
212-15150 Skin right, leg, 3G bleed skin with 1 hole
212-26050 Skin left, leg
212-26250 Leg Skin Left Tibial IO
381106 Rigid Teeth
212-24150 Pneumothorax Bladder Set (pkg. 2)
212-24250 Pleura, chest drain (pkg. 20)
212-11050 Chest Rise Bladder (pkg. 4)
212-21150 SimMan 3G Cricothyroid Tape
250-21050 Airway Lubricant
212-24150 Pneumothorax Bladder Set (pkg. 2)
212-24250 Pleura, chest drain (pkg. 20)
212-24350 Sternal IO Unit (pkg. 4)
212-25250 IM Pad (Intra-muscular Pad) (pkg. 4)
212-26150 Tibial IO Unit (pkg. 4)
212-11150 Lung Bag (pk. 2)
212-11250 Chest Drain Ribs Set (left and right)
212-25350 Inline Filter, Blood (pkg 5)
Modied Clinical Accessories
212-17050 SpO
2
probe with USB connector
200-00550 Cuff assy, Blood pressure
212-17055 USB SP02 probe interface
Tool Kit
212-18350 Repl. Tool Arm, Allen Key 8mm
212-18450 Repl. Tool, IV filter, Screwdriver Pozi no. 1
Support Material
212-19150 User Guide
212-19350 Quick Setup Guide, poster
SimMan 3G Software
400-01050 LLEAP Software + 1 License
SimMan 3G Bleeding Module kit
212-07850 Amputated Arm SimMan 3G
212-07950 Gunshot arm SimMan 3G
212-08150 Amputated Leg SimMan 3G
212-08250 Gunshot Leg SimMan 3G
212-08350 Hardware Kit
212-07650 Arm Adapter Screw
212-14250 Arm Adapter
TROUBLESHOOTING
