HELM STATION
12
SPECIFICATIONS
LAGOON 39
1 4 5
9
10 11 12 13
5 - Screen / repeater for electronic (optional).
6 - Windlass control + chain counter
(depending on finish).
7 - Screen / repeater for electronic (optional).
8 - Engines controls.
9 - Electric winch control (option).
10 - Steering wheel.
11 - Port engine panel.
12 - Cup holder.
13 - Starboard engine panel.
1 - Screen / repeater for electronic (optional).
2 - Screen / repeater for electronic (optional).
3 - 12 V socket.
4 - Compass.
2 6 873
