HEATING
58
UTILITY ABOARD
LAGOON 39
THERMOSTAT +
VENTILATION SWITCH
HEATER FAN
Please note: you can find the same locations
in the other accommodation versions except for the
“standard” two cabins version".
1 - Heating / control / timer.
2 - Water system valves.
3 - Fuel tanks.
4 - Boilers + water system valves.
5 - Boiler exhaust outlet.
5
4
3
5
4
3
HEATING CONTROL / TIMER
HEATING SYSTEM
VALVES
BOILER
+ VALVES
2
2
1
2
2
