ELECTRICITY
77
7
ELECTRICITY
l
GENERATOR
The generator (optional extra) is located in the port locker of the
forward swim deck.
Its function is to re-supply the batteries via the chargers and supply
110 V - 220 V electricity on board.
OPERATION
After turning ON the cut outs located in the port locker of the forward
swim deck, the generator can be turned on by using the control di-
rectly on the generator or in the cupboard to the right of the companion
ladder in the port float.
- Make sure that the seawater cooling valve (access under the floor of
the port passageway) and separator drain valve (access under the floor
of the port passageway) are open.
- Select the fuel tank using the pull rod located in the port locker of the
forward swim deck.
For the use and maintenance of the generator, please refer to its
instruction guide.
n 7.3 110 V - 220 V circuit
l
SHORE POWER SOCKETS
Both shore supply sockets are located in the starboard transom.
They supply the 220 V circuit and the battery chargers, as well as the
air conditioning.
Before you plug in or unplug the boat / shore power supply cable,
switch off the shut off device connected to the shore supply.
Connect the boat / shore power supply cable in the boat before
connecting it to the shore supply socket.
Unplug the boat / shore supply cable on shore first.
Close the protecting cover of the shore supply socket when you do
not use the plug.
The shore power plants are protected by circuit breakers located in
the starboard engine compartment (+ two automatic breakers located
under the chart table in 110 V version).
LAGOON 39
WARNING
Before using the shore power socket, imperatively
check the shore power is 32 Ah.
DANGER
Never let the end of the boat / shore supply cable
hang in the water; the result may be an electric field
liable to hurt or kill the swimmers nearby.
