Lagoon 39 - Electric Distribution

SUMMARY FOR THE 110 V - 220 V COMPONENTS
84
ELECTRICITY
LAGOON 39
GENERATOR
Force 7 Kva in 220 V 100% of its charge in 220 V - 50 Hz
Force 9 Kva in 110 V 100% of its charge in 110 V - 60 Hz
SHORE POWER SOCKETS
Shore power socket Board 220 V - 50 Hz 32 A simple shore power socket Starboard transom connection
Shore power socket Air conditioning 220 V - 50 Hz 32 A simple shore power socket Starboard transom connection
Shore power socket Board 110 V - 60 Hz (US version) 32 A simple shore power socket Starboard transom connection
Shore power socket Air conditioning 110 V - 60 Hz (US version) 50 A simple shore power socket Starboard transom connection
ELECTRIC DISTRIBUTION
Left selector Air conditioning supplied by generator or shore power
Right selector Board supplied by generator or shore power (or 12 V / 220 V - 2000 Va inverter)
CHARGE
1 x 220 V / 12 V - 40 A charger Recharge of the service bank by generator or shore power
1 x 220 V / 12 V - 40 A charger optional extra Engine batteries charger supplied by the generator or the shore
