Lake Shore Model 325 Temperature Controller User’s Manual
Operation 4-27
Table 4-4. Default Values
Control Setup
Control Input ................... Input A
SP Units ........................... Temp K
Control Mode .................. Closed
Power Up ......................... Disable
Setpoint Ramp ................. Off
Heater Output Display ..... Current
Display Format
Display Location 1 .......... Input A / Temp K
Display Location 2 .......... Input B / Temp K
Display Location 3 .......... Setpoint
Display Location 4 .......... Heater Output
Heater
Heater Range ................... Off
Input Setup – Diode/Resistor Configuration
Input Type ....................... Silicon Diode
Curve ............................... DT-470
Input Setup – Thermocouple Configuration
Input Type ....................... Thermocouple/25mV
Curve ............................... Type K
Room Comp .................... On
Room Cal ........................ Cleared
Interface
Baud ................................ 9600
IEEE Address .................. 12
IEEE Terminators ............ CR/LF
Keypad Locking
Mode ........................................ Unlocked
Lock Code ............................... 123
Loop
Selected Loop .......................... Loop 1
PID/Manual Heater Power (MHP) Output
Proportional (P) ....................... 50.0
Integral (I) ................................ 20.0
Derivative (D) .......................... 0.0
MHP Output ............................ 0.000%
Remote/Local
Remote/Local .......................... Local
Setpoint
Setpoint Value ......................... 0.000K
Tuning
Tuning Mode ........................... Manual PID
Zone Settings – All Zones
Setpoint Limit .......................... 0.000K
Proportional (P) ....................... 50.0
Integral (I) ................................ 20.0
Derivative (D) .......................... 0.00
Manual Output ......................... 0.000%
