15
5 Operating Control and Displays
5.2 Menu Functions
The menu is divided into three paths:
INFO
Select INFO path for information about the following:
• Burner
• Faults/Fault history
• Software version
• Display of check sums
• Serial number
• Actuator positions (current damper position for each channel)
• Digital inputs/outputs
MANUAL
Select MANUAL to:
• start and stop burner by hand
• adjust internal burner firing-rate
SETTINGS
Select the SETTINGS path for getting information/make changes to:
• Password
• Burner settings (display and settings)
• Actuator elements settings (display)
• Air/fuel control system
• Deletion of curve sets
• Display settings
INFO
MANUAL
SETTINGS
