9 Faults/Warnings
9 Faults/Warnings
Messages in plain text (see chapter 7.1.3 Status Signals).
• by (optional) display and operating unit, in menu [diag]
• by Remote-display software (optional)
• by LED row, LED 7 to 12, on LT2's processor board
If several faults/warnings are present, they can be called up in sequence by activating the T2
multifunction key.
9.1 Faults
Message by LED line, LED 7 to 12, LED 12 flashes
Faults (flashing)
Legend LED
is off
flashes
lights up
12 11 10 9 8 7 Fault No.:
Display of active faults (red), flashes
No warnings/faults active
1 Probe voltage < -30 mV
2 Probe heater faulty
5 Probe broken wire/probe faulty
9 Dynamic response missing
11 Fault analogue outputs
