lancer Twin Pour - LED Lighting Configuration; DIP Switch Legend

33
30"LED
30" LED
30" LED
18" LED
18" LED
LED DRIVER
JUMPER
JUMPER
PLUG
RECEPTACLE
PR
PR
P
R
P
R
P
R
P
R
P
R
P
FS44 LIGHTING CONFIGURATION
*= DENOTES DEFAULT
32
SW2 SWITCH 2: POSITION DOES NOT
MATTER
4
ON
LANCER PN: 06-3289/01
SW1
5258
ON
1
ON
SW1
8
SW1 SWITCH 2: NOT USED FOR
MODEL 4900
1
6
873
6
SW2 SWITCH 1: MUST BE ON FOR
MODEL 4900
SW2
7
6
7
6
2
2
3 83
4
7
4
5
SW1 SWITCH 1: NOT USED FOR
MODEL 4900
ON
5
4
SWITCH #
AGITATOR ON
TIME
56
OFF OFF 11 SECONDS
OFF ON 9 SECONDS
*ON OFF 7 SECONDS
ON ON 5 SECONDS
SWITCH #
AUGER RUN TIME
78
OFF OFF
6 SEC DISPENSED
OFF ON
9 SEC DISPENSED
*ON OFF
12 SEC DISPENSED
ON ON
15 SEC DISPENSED
SWITCH #
AUTO AGITATE
OFF TIME
34
*OFF OFF
NO AUTO AGITATION
OFF
ON
20 MINUTES
ON OFF 40 MINUTES
ON ON 60 MINUTES
DIP Switch Legend
LED Lighting Conguration
If installing a Scotsman
®
Pellet icemaker, set the auto agitation time to every 60 minutes.
NOTE
