4
PRE-INSTALLATION
• Units are equipped with an automatic agitation system and will activate unexpectedly.
• CAUTION: Do not place hands or foreign objects in the ice bin tank. Unplug the dispenser during servicing, cleaning, and
sanitizing.
• CAUTION: To avoid personal injury, do not attempt to lift the dispenser without assistance. For heavier dispensers, use a
mechanical lift.
! Automatic Agitation
This unit emits a sound pressure level below 70 dB
DIMENSIONS
Width: 44.00 inches (1118 mm)
Depth: 31.13 inches (790.70 mm)
Height: 39.36 inches (999.74 mm)
WEIGHT
Shipping: 585 lbs (265 kg)
Operating (w/ Ice): 745 lbs (338 kg)
Ice Capacity: 312 lbs (142 kg)
ELECTRICAL
115 VAC / 60 Hz / 6.0 Amps
PLAIN WATER SUPPLY
Min Flowing Pressure: 75 psi (0.516 MPa)
CARBONATED WATER SUPPLY
Min Flowing Pressure: 75 psi (0.516 MPa)
Max Static Pressure: 125 psi (0.862 MPa)
CARBON DIOXIDE (CO
2
) SUPPLY
Min Pressure: 70 psi (0.483 MPa)
Max Pressure: 80 psi (0.552 MPa)
FITTINGS
Carbonator Inlets: 3/8 inch barb
Plain Water Inlets: 3/8 inch barb
Brand Syrup Inlets: 3/8 inch barb
Ambient Flavor Inlets: 3/8 inch barb
CO
2
Inlet: 3/8 inch barb
Carb Water Outlet: 3/8 inch barb
Plain Water Outlet: 3/8 inch barb
A. Top Cover
B. Merchandiser
C. Touchscreen Display
D. Splash Plate
E. Cup Rest/Drip Tray
A
B
C
D
E
Specications & Features
