NCA-4020 User Manual
29
E8 I2C_SFP_SCL5 L8 N/A
D8 I2C_SFP_SDA5 K8 N/A
F9 IPMI_CLK M9 N/A
E9 IPMI_DAT L9 N/A
E10 IO_BOARD_PWROK L10 SMB_BMC_SCL6
D10 P35V_OK K10 SMB_BMC_SDA6
PIN Description PIN Description
G1 GND A1 GND
G3 GND A3 GND
G5 GND A5 GND
G7 GND A7 GND
G9
GND
A9
GND
J2 GND C2 GND
J4 GND C4 GND
J6 GND C6 GND
J8 GND C8 GND
J10 GND C10 GND
K1
GND
D1
GND
K3 GND D3 GND
K5 GND D5 GND
K7 GND D7 GND
K9 GND D9 GND
M2 GND F2 GND
M4 GND F4 GND
M6 GND F6 GND
M8 GND F8 GND
M10 GND F10 GND
