5: Using DeviceInstaller
EDS1100/2100 Device Server User Guide 34
Group Configurable field. Enter a group to categorize the EDS1100/2100
device server. Double-click the field, type in the value, and press Enter
to complete. This group name is local to this PC and is not visible on
other PCs or laptops using the DeviceInstaller application.
Comments Configurable field. Enter comments for the EDS1100/2100 device
server. Double-click the field, type in the value, and press Enter to
complete. This description or comment is local to this PC and is not
visible on other PCs or laptops using DeviceInstaller.
Device Family Shows the EDS1100/2100 device family type as “EDS”.
Type Shows the specific device type, such as “EDS1100” or “EDS2100”.
ID Shows the EDS1100/2100 ID embedded within the unit.
Hardware Address Shows the EDS1100/2100 hardware (MAC) address.
Firmware Version Shows the firmware currently installed on the EDS1100/2100.
Extended Firmware Version Provides additional information on the firmware version.
Online Status Shows the EDS1100/2100 status as Online, Offline, Unreachable (if
the EDS1100/2100 is on a different subnet), or Busy (if the EDS1100/
2100 is currently performing a task).
IP Address Shows the EDS1100/2100 device’s current IP address. To change the
IP address, click the Assign IP button on the DeviceInstaller menu bar.
IP Address was Obtained Displays Dynamically if the EDS1100/2100 automatically received an
IP address (e.g., from DHCP). Displays Statically if the IP address was
configured manually.
If the IP address was assigned dynamically, the following fields appear:
Obtain via DHCP with value of True or False.
Obtain via BOOTP with value of True or False.
Subnet Mask Shows the subnet mask specifying the network segment on which the
EDS1100/2100 resides.
Gateway Shows the IP address of the router of this network. There is no default.
Number of Serial Ports Shows the number of serial ports on this EDS1100/2100 unit.
Supports Configurable Pins Shows False, indicating configurable pins are available on the
EDS1100/2100 unit.
Supports Email Triggers Shows True, indicating email triggers are available on the EDS1100/
2100 unit.
Telnet Supported Indicates whether Telnet is enabled on this EDS1100/2100 unit. Shows
True.
Telnet Port Shows the EDS1100/2100 port for Telnet sessions.
Web Port Shows the EDS1100/2100 port for Web Manager configuration.
Firmware Upgradable Shows True, indicating the EDS1100/2100 firmware is upgradable as
newer versions become available.
Current Settings (continued) Description
