8: Line and Tunnel Settings
EDS1100/2100 Device Server User Guide 64
For commands that can take address information (ATD, ATDT, ATDP), the destination address
can be specified by entering the IP Address, or entering the IP Address and port number. For
example, <ipaddress>:<port>. The port number cannot be entered on its own.
For ATDT and ATDP commands less than 255 characters, the EDS1100/2100 replaces the last
segment of the IP address with the configured Connect Mode remote station address. It is possible
to use the last two segments also, if they are under 255 characters. For example, if the address is
100.255.15.5, entering ATDT 16.6 results in 100.255.16.6.
When using ATDT and ATDP, enter 0.0.0.0 to switch to the Command Line Interface (CLI). Once
the CLI is exited by using the CLI exit command, the EDS1100/2100 reverts to modem emulation
mode. By default, the +++ characters are not passed through the connection. Turn on this
capability using the modem echo pluses command.
To configure modem emulation for a specific tunnel:
1. Select Tunnel on the menu bar, if you are not already in the Tunnel web page.
2. Select a tunnel number at the top of the page.
3. Select Modem Emulation. The Modem Emulation page for the specific tunnel appears.
ATXn Command does nothing and returns OK status.
ATUn Accept unknown commands. (n value of 0 = off. n value of 1 = on.)
AT&V Display current and saved settings.
AT&F Reset settings in NVR to factory defaults.
AT&W Save active settings to NVR.
ATZ Restores the current state from the setup settings.
ATS0=n Accept incoming connection.
N value of 0—Disable
N value of 1—Connect automatically
N value of 2+—Connect with ATA command.
ATA Answer incoming connection (if ATS0 is 2 or greater).
A/ Repeat last valid command.
Table 8-20 Modem Emulation Commands and Descriptions (continued)
Command (continued) Description
