7: Network Settings
EDS1100/2100 Device Server User Guide 43
Network 1 Ethernet Link
This page shows the current negotiated Ethernet settings and lets you change the speed and
duplex settings.
To view and configure the Ethernet link:
1. Click Network on the menu bar and then click Network 1 > Link at the top of the page. The
Network 1 (eth0) Ethernet Link page appears.
Figure 7-4 Network 1 Ethernet Link
The Status table shows the current negotiated settings. The Configuration table shows the
current range of allowed settings.
2. Enter or modify the following settings:
Table 7-5 Network 1 Ethernet Link
3. Click Submit. The changes take effect immediately.
Note: The following section describes the steps to view and configure Line 1 settings;
these steps apply to other line instances of the device.
Network 1-Ethernet Link
Settings
Description
Speed Select the Ethernet link speed. Default is Auto.
Duplex Select the Ethernet link duplex mode. Default is Auto.
