4: Configuration Using Web-Manager
Connect Mode: Passive Connection
Accept Incoming
Select Yes to accept incoming connections. The default
setting is Yes.
Password Required Determines whether a password is required for an incoming
passive connection. This field is not available when a
password is set for Telnet mode. The default setting is No.
Password
If Password Required was set to Yes, enter the password for
passive connections.
Modem Escape Sequence
Pass Through
Disable or enable the UDS’s ability to send the escape
sequence. The default is Y (Yes) (send the escape
sequence).
Connect Mode: Active Connection
Active Connect
Select None (default) to disable Active Connect. Otherwise,
indicate the connection type from the drop-down list:
With Any Character: Attempts to connect when any
character is received from the serial port.
With Active Mdm Ctrl In: Accepts external
connection requests only when the Modem Control
In input is asserted.
With Start Character: Attempts to connect when it
receives a specific start character from the serial
port. The default start character is carriage return.
Manual Connection: Attempts to connect when
directed by a command string received from the
serial port.
Auto Start: Automatically connects to the remote IP
address and port after booting up.
Start Character
If Active Connect is set to With Start Character, enter the
start character in this field. The default setting is 0D.
Modem Mode Indicates the on-screen response type when in Modem Mode
(if Modem Mode is enabled). The default setting is None.
Show IP Address After
Ring
Indicates whether to display the remote IP address upon
connection. The default setting is Yes.
Endpoint Configuration
Local Port Enter the local port number.
Auto increment for active
connect
Select to auto-increment the local port number for new
outgoing connections. The range of auto-incremented port
numbers is 50,000 to 59,999 and loops back to the beginning
when the maximum range is reached. Disabled by default.
Remote Port Enter the remote port number.
Remote Host Enter the IP address of the remote device.
UDS1100 User Guide 33
