NMS045 Reference Manual NMS045 Features 1-2
1.2 NMS045 Features
Acoustic Measurement
The area sound is measured with the SoundAdvisor
TM
Model 831C
sound level meter using a prepolarized microphone and preamplifier
that are environmentally protected in a shroud.
Power Options
A solar panel can effectively charge the 12 V battery to power the
system continuously without interruption. Alternatively, an AC power
source will keep the battery charged.
Connectivity
Connect to a cellular network using the RV50X Cellular Gateway so that
you can access the 831C to view/download data from a PC anytime. You
can access the interface from a web browser, so an external device may
control the system. Ethernet and WiFi are viable connection options as
well.
Intrusion Detection
The anti-theft system will alert through email when the door has been
opened. There is a magnet on the door and the main plate. When
separated it sends a signal to the RV50X Gateway, and then an alert is
sent to the email address specified in the gateway settings.
1.3 Components
TRP019 Pole
TRP019 is a 17 foot pole that when used with the 426A12-NPT and
EPS2116 is designed to mount the PRM2106-FF at approximatively 20
feet above ground. It is installed by a local contractor using the Larson
Davis mechanical drawing. The foundation is poured, pole mounted,
and the EPS045 box installed by a local contractor.
EPS045
The EPS045 is an environmentally protected fiberglass case used to
protect and house the NMS045 system. It includes:
• Fiberglass case
• Back panel, distribution plate, and battery plate
• Grounding cable
Depending on mounting option, you will receive items to meet your
specific mounting requirements. A system with a solar or weather
system will determine holes and accessories for the EPS045.
