Maintenance
Lastec Mower Specifications, 4520
Maintenance Lastec//061714 5-7
5
Engine, 4520
1
Left and Right hydraulic wheel motors are the same unit -- direction is controlled through hose attachements. See
Hydraulic System Diagram following this chart.
2
Lastec hydraulic fluid is equivalent to Special Mobil 20W50 with options and Mobil One Synthetic 15w50
Model Engine, 45HP Turbo Kubota V1505TE-1-3 064346
Bore and Stroke 78mm x 78.4mm
Total Displacement 1.5L / 91.41 cu. in
Power 45HP
High / Low Idle Speed 3000 RPM / 1200 RPM
Compression Ratio 21:1
Dry Weight 251 lbs.
Oil API Service Class CJ-4, Shell Rotella T, SAE 10W-30
Oil Capacity w/Filter Approx. 7.1 US qt. (6.7L)
Oil Filter Kubota 16271-32090 018050
Fuel Diesel Fuel No.2-D (ASTM D975)
Fuel Capacity 14 Gal
Fuel Filter Filter, Fuel Element Replacement 028084
Air Filter Element, Air Cleaner Primary 048520
Air Filter Element, Air Cleaner Safety 048519
Battery Battery, 12V 524/26A 028004
Coolant Capacity 4.0L / 1.06 Gal
Fan Belt Belt, Fan-Kubota 028514
