Lastec Mower Specifications, 4520
5
5-6 Lastec//061714 Maintenance
5.13 Lastec Mower Specifications, 4520
Mower
Transmission
Mower Deck Configuration (5) 25” Articulating Decks
Width 120”
Blades (5) 25” x 2 1/2” x 1/4” High Lift P701
(5) 25” x 2 1/2” x 1/4” Low Lift P849
(5) 25" Gator Mulching P848
(5) 25” x 2 1/2” x 1/8” Low-Lift Ultra 063266
Blade Tip Speed Max 16,600
Mower Deck Height Range 1” to 4-1/2”
Paint Red, 12 oz. spray P299
Black, 12 oz. spray L07467
Gross Weight 2142 pounds (971.6kg)
Front Wheel Assemblies 13” x 6.5 x 6 Reliance 045986
Drive Wheel Assembly 26” x 12-12 w/Centered Rim
067965
1
1
067965 replaced 059929 26” x 12-12 w/Offset Rim Tire Assembly (Serial #47050213 and later).
Rim alone 12” x 8 1/2” SYM OS 067966
Tire alone 26” x 12-12 059928
Gage Wheels 11” x 4” x 5” Hollowmatic 063767
Clutch Warner 8.3 C Cross Section
067733
2
2
067987 Clutch Assembly equipped with 067733 Warner 8.3 C Cross Section Clutch replaced 064404 Warner
Electric C-Belt Clutch Assembly equipped with 058500 Warner C Cross Section Clutch (Serial #46331112 and
later).
Main Drive Belt Belt, C138 Mule Drive
063211
3
3
063211 C138 Mule Drive Belt replaced 062001 C132 Mule Drive Belt (Serial #46331112 and later).
Deck Drive Belts, Center Belt, B148 Deck Drive 048272
Wing Deck, Right Belt, Insta-Power 85890 P706
Wing Deck, Left Belt, Insta-Power 85950 063879
Maximum Forward Speed Infinitely variable up to 8.5 mph (13.7kh)
Noise Levels 105 dB or lower
Hydraulic Pump, Left Pump, PW Series Left 049235
Hydraulic Pump, Right Pump, Hydrogear 21cc w/Aux. w/Return 058505
Hydraulic Motors Left
1
Motor, Hydraulic MB29 018741
Hydraulic Motors Right Motor, Hydraulic MB29 018741
Hydraulic Fluid
2
Lastec Hydro Oil 040642
Hydraulic Fluid Filter 25 Micron, & GPM Full-flow, 3/8” NPT P620
Hydraulic Fluid Capacity 5 quarts
Hydraulic Pump Drive Belt Belt, AX-62 044925
