Launch TLT245AT / TLT250AT(C) Two-post lift’s Installation manual
19
No. Code Name
1 201020657 TLT245AT power side column
2
201020676
TLT245AT offside column
3
201020928 TLT245AT extension column
4
103202858 TLT245AT protective cover inside column
5
103202859 TLT245AT cover for extension column
6 103010498 Screw M5×8
7 103040132 Flat washer 5
8 103203019 Side positioning shim
9
103020188 Bolt M5*10
10
103202811
Connecting bracketⅠ
11 103020104 Bolt M12×35
12 103040044 Spring washer 12
13 103040110 Flat washer 12
14 103030129 Nut M12
15 103040123 Flat washer 10
16 103040122 Spring washer10
17 103020120 Bolt M10×20
18
103202812
Connecting bracketⅡ
19
201011176 TLT245AT reinforced bracket
20
103202906 Power unit bracket
21
103020190 Screw M6×10
22 103201545 TLT245AT bracket
23
102100075 Limit switch
24
103040109 Flat washer 4
25
103010426 Screw M4×12
26
103010429
Screw M4×25
27
201024606
Wire through block assembly
28
103020163
Bolt M6×25
29
103010134 Flat washer 8
30
103202817 TLT245AT inner top beam
31 103202818 TLT245AT outer top beam
32 201011258
BushingⅠ
33
103200699
Bushing 2520
34 103203017 Pulley
35
103050035
Returning ring 25
36
103200966 Asymmetric axle
37 201011257
BushingⅡ
38
103200967 Symmetric axle
39 103020126 Bolt M12×25
40
103201070 Bottom cover for column
41 103260338 TLT245AT steel cable
43
103060342
Pin 3×26
