Launch TLT245AT / TLT250AT(C) Two-post lift user’s manual
1
1. Outline
1.1 Model Description
Model Description
TLT245AT clear-floor 2-post lift 4.5T economical clear-floor 2-post lift
TLT250AT(C) clear-floor 2-post lift 5T economical clear-floor 2-post lift
1.2 Purpose
TLT245AT/TLT250AT(C) are of safe and simple operation
and applicable for the lifting of various small and
medium-sized vehicles with total weight below 4.5t/5t in
garage and workshop
1.3 Functions and Features
z The cable and oil pipe are fully concealed, with
decent and elegant appearance.
z Designed based on the international standard,
meeting the demand of the garage and workshop.
z Top limit switch, effectively protecting the vehicle
from overhead collision.
z Dual hydraulic cylinders drive, stable lifting and
lowering.
z Automatic full-scope safety lock, safe and simple in
operation.
z Adopt two steel cables for equalization, force two
carriages to move synchronously, and effectively
prevent the vehicle from tilting.
z Lowest height of lifting pad is 110mm, good for
repairing low chassis or low profile car.
1.4 Technical Specifications
Basic parameters of the equipment:：
Model Rated load
Lifting
height
Rising
time
Descending
time
Net weight
960kg
2116 lb
2888mm
113.7in
4130mm
162.6in
4810mm
189.3in
Noise:
Working noise: ≤ 75dB（A）
Power unit
Working pressure：18MPa TLT245AT
20MPa TLT250AT(C)
Electrical parameters of the machine：
Motor (optional)
Voltage：According to client’s requirement
Single phase: 110V /60Hz ; 220V/50Hz
Single phase: 200V/ 60Hz
Three phase: 380V/50Hz
Power：2.2Kw TLT245AT 3 Kw TLT250AT(C)
