Launch TLT245AT / TLT250AT(C) Two-post lift user’s manual
2
1.5 Environmental Requirement
Working temperature： -5℃～+40℃ Relative humidity: Temperature +30℃，relative humidity 80%
Transport/storage temperature：-5℃～+40℃ Height above sea level：No more than 2000m
2. Lift Structure
TLT245AT structure is shown as Fig1, Fig2a, Fig3a:
TLT250AT(C) structure is shown as Fig1, Fig2b, Fig3b：
TLT245AT：3725mm(146.7in)
TLT250AT(C)
：4700mm(185in)
TLT245AT：2750mm(108.3in)
TLT250AT(C)
：3350mm(131.9in)
TLT245AT：3840 mm(151.2 in)
TLT250AT(C)
：4810mm(189.4in)
1850 mm(72.8 in)
min110mm(4.33in)
Fig 1
