Launch TLT245AT / TLT250AT(C) Two-post lift’s Installation manual
21
226
103202107 Double adjustment screw cove
227
103202106 Supporting seat
228
103050091
Returning ring 30
229
103050090
Returning ring 45
401 104090074 Cover for safety mechanism
402 103203057 Safety block
403 103203056 Changing plate
404 103201450
SpringⅠ
405 103201451
SpringⅡ
406 103201455 Pin of safety block
407 103203055 Small pulley
408 103201454 Handle of safety release
409 103260186
Handle BM10×50（black）
410 103010393 Screw M8×12
411 103040134 Washer 8
412 103203061
Adjustment washerⅠ
413 104130210 Rubber pad
414 103050021 Returning ring 9
415 103060333 Pin 6X40
417 101060019
TLT245AT ￠1.6 steel cable
418 103260179 Steel cable clamp
419 103050025 Returning ring 20
420 104090073 Sub-cover for safety mechanism
601
102100074
Button，NB2-BE101，green color
602
102110059
Contactor(Shilin）,S-P11,AC24V
603
102130043
Transformer，JBK-25,220V,380V/24V
604
102990109
Power switchLW39B-16RE04/-2-GR（Small）
605
104090089
Waterproof Case，240*160*90，（black）
606
102160391 cable joint PG13.5
607
102160388 cable joint PG9
608
103040109
Flat washer C class，GB/T95-1985,φ4(white zinc-plated)
609
103030009
Hex nut，GB/T6170-2000，M4(white zinc-plated)）
610
103240319 ground copper bars
611
103030009
Screw ，M4*18
612
102100090 Emergency stop button LA39-11Z/r
