Launch TLT245AT / TLT250AT(C) Two-post lift’s Installation manual
27
43 201011257
BushingⅡ
44 103200967 Symmetric axle
45
103200966 Asymmetric axle
46 103203019 Side positioning shim
47
103020188 Bolt M5*10
101 Power unit （optional）
102
104120136 HP oil hose L=880
103
103100170 fitting of pump (for domestic)
104 104120148 TLT250AT(C) HP oil hose L=6110
105
103100172 T fitting
106
104120117
HP oil hose L=930
107 103201847 TLT250AT(C) Flow-control fitting assembly
108
103040188
Seal gasket 18
109 102200321 Hydraulic cylinder
110
103040157 Seal gasket 14
111
103100198 Fitting
112
104120095 Oil hose of sub-cylinder L=4250
113
104120177 TLT250AT(C)widened HP hose L=1600
201
201021093 TLT250AT(C) Carriage
104990134
TLT250AT(C) Sliding blockⅡ
202
104990135
TLT250AT(C) Sliding blockⅠ
203
103202767
TLT250AT(C) Top cover
204
103010473
Screw M10×30
205 104130267 Door rubber pad
206 103010555 Screw M8×12
207
103202184 Top rod assembly
208
103060346 Pin 5×40
209 103060342 Pin 3×26
210
103201914
Spring
211
103201744
Gear block
212
103202778
TLT250AT(C) Pin axle
213
103011102
Screw M10×25
214 103040122 Washer 10
215 103202032 Semi-gear
216
103050030
Returning ring 40
217
201024943
TLT250AT(C) rear arm
218
104130186
Rubber pad on arm
219
103010608
Screw M6×10
220
201024944
TLT250AT(C) middle arm
221
201024945
TLT250AT(C) front arm
