X-431 ADAS PRO Calibration Tool User Manual
8
3 Knowledge of X-431 ADAS PRO Calibration Tool
3.1 X-431 ADAS PRO Calibration Tool
The X-431 ADAS PRO calibration tool mainly includes the following items and
components:
Fig. 3-1 (This figure is fictious and only for illustrative purpose. It is subject to change due to
product improvements)
