LAUNCH X-431 PRO3 User Manual
5
Press it for 3 seconds to turn it off.
Press it for 8 seconds to perform forced
shutdown.
2 VOLUME +/- Key To adjust the volume.
3 LCD Screen
4 Microphone
5
USB/Charging
Port
To connect to AC outlet for charging.
To connect to PC for data exchange.
6 Rear Camera
7 Speakers
2.3 VCI Connector (Only applies to 12V cars)
The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle’s DLC (Data Link Connector) socket directly or via
OBD II extension cable to read the vehicle data and then send it to the X-431
PRO3 handset via Bluetooth.
