CS-D1008E Closed Loop Stepper Drive User Manual
Page | 2
2. Specifications
2.1 Electrical Specifications
Parameters
Min
Typical
Max
Unit
Output Current (peak)
0.5
-
8.0
A
Operating Voltage
24
30 - 90
110
VDC
18
20 - 70
80
VAC
Logic signal current
7
10
16
mA
Pulse input frequency
(5V @ 50% dutycycle)
0
-
500
kHz
Pulse input frequency
(24V @ 50% dutycycle)
0
-
200
KHz
Minimal pulse width
1μS @ 5V,
or 2.5μS @ 24V
-
-
μS
Minimal direction setup
5.0
-
-
μS
Isolation resistance
100
MΩ
2.2 Environment
Cooling
Natural Cooling or Forced Cooling
Operating Environment
Environment
Avoid dust, oil fog and corrosive gases
Humidity
40%RH－90%RH
Operating Temperature
0°C － 40°C (32°F - 104°F)
Vibration
10-50Hz / 0.15mm
Storage Temperature
-20°C － 65°C (-4°F - 149°F)
Weight
Approx. 570 g (20.2 Oz)
