CS-D403 Closed Loop Stepper Drive User Manual
Page | 10
6.1 Microstep Resolution (SW1-SW4)
Microstep resolution is set by SW1, 2, 3, 4 of the DIP switches as shown in the following table:
Steps/Revolution
SW1
SW2
SW3
SW4
Software Configured (Defaulted to 1600)
on
on
on
on
800
off
on
on
on
1600
on
off
on
on
3200
off
off
on
on
6400
on
on
off
on
12800
off
on
off
on
25600
on
off
off
on
51200
off
off
off
on
1000
on
on
on
off
2000
off
on
on
off
4000
on
off
on
off
5000
off
off
on
off
8000
on
on
off
off
10000
off
on
off
off
20000
on
off
off
off
40000
off
off
off
off
6.2 Other DIP Switch Settings (SW5-SW8)
Function
On
Off
SW5
Default Direction
CW (clockwise)
CCW (counterclockwise)
SW6
Auto Tuning
No
Yes
SW7
Pulse Model
CW/CCW (double pulse)
PUL/DIR (single pulse)
SW8
Pulse Edge
Falling
Rising
7. Typical Connection
A complete closed loop stepper system should include a stepper motor with encoder, CS-D403 drive, power supply and
